Maxliner Venture Canopy Gen 1 to Suit Ford Ranger Next-Gen & Raptor 2022+ Dual Cab — Steel-Reinforced Ute Canopy

Will This Fit My Ranger?

Fits	Ford Ranger Next-Gen and Ranger Raptor, July 2022 onwards — Dual Cab pick-up
Does NOT fit	Ford Ranger PX / PX2 / PX3 (2011–2022) — a completely different tub, nothing carries over. Ranger Super Duty is Gen 2 only. Also does not fit Super Cab or cab chassis.
Factory sports bar	A canopy covers the tub opening entirely, so a factory sports bar normally has to come off. Call us and we will confirm for your grade.

Gen 1 or Gen 2 — What You Get For The Extra $1,700

Straight answer, because the price gap is real.

Gen 1 ($3,495) — driver-side switch and a battery-powered interior light. Same steel-reinforced frame, same push-button windows, same styling. Maxliner does not publish a rated roof load for it.

Gen 2 ($5,195) — dual-side switching so you can open the windows from either side of the ute, a hard-wired interior light that never needs batteries, premium roof rails included, and a published 150kg dynamic / 350kg static roof rating. The Gen 2 also covers the Ranger Super Duty.

If you are running a roof top tent, a rack or any real weight on the roof, buy the Gen 2 — the published rating is the thing you actually need. If the canopy is for secure dry storage and you will never load the roof, this Gen 1 does the same job for $1,700 less.

Features

▪ Steel-reinforced internal frame — built to carry rooftop tents, racks and trade gear rather than just cover the tub

▪ Handle-free push-button side windows — nothing to catch or break, and easy to open with your hands full

▪ Lift-up front window — ventilation on hot days and access through to the cab

▪ Interior light — driver-side switch with a battery-powered interior light

▪ Central locking compatible — ties into your Ranger's existing locking

▪ No-drill installation — fitted without drilling into your tub

▪ Styling — rear spoiler and colour-coded lower glass trim, in full body colour or two-tone black accent

Specifications

▪ Brand — Maxliner Australia, Venture Canopy range

▪ Roof load — the steel-reinforced frame is built to carry roof load, but Maxliner does not publish a rated figure for the Gen 1. If you are mounting a roof top tent or a heavy rack, go for the Gen 2, which is rated at 150kg dynamic and 350kg static.

▪ Finishes — Full Body Colour or Two Tone Black Accent

▪ Installation — no-drill

▪ Paint colours available — Code Orange, Cyber Orange, Equinox Bronze, Luxe Yellow, Sedona Orange

Choosing Your Colour

This canopy is made to order in your choice of finish and paint colour. Add it to your cart, then call us on 02 8773 1993 or reply to your order confirmation with your vehicle's paint code and whether you want full body colour or two-tone black accent. We will confirm availability and lead time before anything is built.

Not sure of your paint code? It is on the vehicle's compliance plate — send us a photo and we will read it for you.

Common Questions

How does a canopy affect my payload?
A canopy is dead weight before you load anything into it, and it comes straight off your ute's payload. Add a drawer system and touring gear and it adds up quickly. If you are planning a full build, come and talk to us at Chipping Norton and we will work through the numbers rather than have you end up overloaded.

Can I fit a roof top tent?
There is no published roof rating on the Gen 1, so for tent use we would steer you to the Gen 2 at 350kg static.

Is it dust sealed for outback touring?
The Venture uses sealed lift-up windows and a sealed rear door. As with any canopy, sealing performance depends on correct fitment — a good argument for having it fitted by us rather than doing it yourself.

How long until I get it?
These are built to order in your chosen colour. Call 02 8773 1993 for current lead times before you order.

Collection or Fitment Only — This canopy is available for collection from, or fitment at, our Chipping Norton NSW workshop. Residential delivery is not available. For freight cost to a business or depot address please kindly contact us.

📞 Authorised Maxliner Dealer — Supply & Fit at Chipping Norton NSW — 02 8773 1993

🏆 Backed by Maxliner's Manufacturer Warranty
